Adapters

Inbound and outbound adapters that connect Irrlicht to the outside world.

Inbound Adapters (Event Sources)

Inbound adapters drive events into the application. Each watches a specific agent's transcript files or process activity and emits session lifecycle events that the core state machine consumes.

Claude Code Adapter

Package: core/adapters/inbound/agents/claudecode/
Watches: ~/.claude/projects/**/*.jsonl
Uses the shared fswatcher with recursive directory watching (two-level tree: root/<project>/<id>.jsonl)
Adapter name in session state: "claude-code"

Codex Adapter

Package: core/adapters/inbound/agents/codex/
Watches: ~/.codex/sessions/ (deep nesting: YYYY/MM/DD/*.jsonl)
Uses the shared fswatcher with recursive directory watching
Adapter name: "codex"
Model detection from ~/.codex/config.toml

Pi Adapter

Package: core/adapters/inbound/agents/pi/
Watches: ~/.pi/agent/sessions/ (nested: --<cwd-dashed>--/*.jsonl)
Uses the shared fswatcher with recursive directory watching
Adapter name: "pi"
Model detection from ~/.pi/agent/settings.json
JSONL v3 format with session header, tree-structured entries, and multi-provider support

Aider Adapter

Package: core/adapters/inbound/agents/aider/
Watches: per-CWD transcript file .aider.chat.history.md (markdown, not JSONL)
Process discovery via CommandLineMatch (/aider($| )) since the OS process is python
Adapter name: "aider"
Waiting state is pinned to a trailing ? contract on the most recent assistant block
Stage: alpha — first agent shipped through the /ir:onboard-agent discovery flow

OpenCode Adapter

Package: core/adapters/inbound/agents/opencode/
Watches: SQLite WAL at ~/.local/share/opencode/storage/opencode.db-wal via fsnotify; polls session/part tables on writes
First adapter on the SQLite-backed monitoring path: storage is a single WAL-mode database, not JSONL
Bypasses the JSONL tailer via a MetricsReader on its ProcessOwnedStore source variant for cost + token snapshots
Parent-child session linking via parent_id column — EventNewSession carries ParentSessionID directly, no path-based heuristics
CWD-based PID discovery via pgrep -x opencode
EventRemoved emitted on session.time_archived so the daemon transitions to ready immediately rather than waiting for TTL
step-finish reasons (stop, interrupted, length, error) all map to turn_done
Adapter name: "opencode"
Stage: alpha — closes #100

Process Scanner

Package: core/adapters/inbound/agents/processlifecycle/
Polls once per second per adapter via pgrep -x <name> (exact-name match) or pgrep -f <regex> (command-line match, used by aider); interval backs off when the PID set is stable
Creates pre-sessions (proc-<pid>) before transcripts exist
CWD discovery via lsof
Suppresses ghost pre-sessions when a real transcript exists

Shared File System Watcher

Package: core/adapters/inbound/agents/fswatcher/
Built on fsnotify (kqueue on macOS)
Recursive directory watching
Event types: EventNewSession, EventActivity, EventRemoved
Max age filtering
Race condition handling for new directories

Gas Town Orchestrator

Package: core/adapters/inbound/orchestrators/gastown/
Watches daemon state file + polls gt CLI
Role detection from session CWD paths
State model: global agents, codebases, worktrees, workers, work units

Adapter Interfaces

Every inbound agent adapter is wired up by exporting a single agent.Agent declaration. The daemon's bootstrap in core/cmd/irrlichd/main.go consumes one []agent.Agent slice; core/cmd/irrlichd/wiring.go dispatches each declaration on its Source variant to build the right combination of fswatcher and process scanner. The per-projection helpers in core/adapters/inbound/agents/maps.go derive the parser, PID-discovery, process-name, subagent-count, and metrics-reader maps the rest of the daemon consumes.

An adapter package therefore satisfies the contract by exporting a single top-level Agent() function that returns a fully-populated agent.Agent. Watching the filesystem, scanning processes, and broadcasting events are handled by the shared infrastructure (core/adapters/inbound/agents/fswatcher/, core/adapters/inbound/agents/processlifecycle/) plus the per-adapter watcher when the source needs one (e.g. OpenCode's SQLite WAL watcher).

Adapter declaration — `agent.Agent`

Defined as a sealed-sum across three orthogonal axes in core/domain/agent/: Identity (name + branding), Process (how to find the OS process), and Source (where the conversation lives).

// Top-level declaration — Identity × Process × Source.
type Agent struct {
    Identity Identity
    Process  Process
    Source   Source
}

type Identity struct {
    Name         string // adapter label on events, e.g. "claude-code"
    DisplayName  string // human-readable label, e.g. "Claude Code"
    IconSVGLight string // raw <svg>…</svg> markup, 14×14 (light theme)
    IconSVGDark  string // raw <svg>…</svg> markup, 14×14 (dark theme)
}

// Process bundles process-recognition with session-to-PID resolution.
// PIDForSession lives here rather than on Source so every variant gets
// it uniformly.
type Process struct {
    Match         ProcessMatcher
    PIDForSession PIDDiscoverFunc
}

type PIDDiscoverFunc func(
    cwd, transcriptPath string,
    disambiguate func([]int) int,
) (int, error)

// ProcessMatcher — sealed sum, exactly one of:
type ProcessMatcher interface{ isProcessMatcher() }

type ExactName struct {
    Name string // e.g. "claude" — runs as `pgrep -x claude`
}

type CommandPattern struct {
    Regex *regexp.Regexp // matched against the full command line
                        // via `pgrep -f`, e.g. "/aider($| )"
}

// Source — sealed sum, exactly one of:
type Source interface{ isSource() }

// JSONL transcripts under a fixed $HOME-relative directory tree
// (Claude Code, Codex, Pi).
type FilesUnderRoot struct {
    Dir    string     // path relative to $HOME, e.g. ".claude/projects"
    Parser FileParser // JSONLineParser or RawLineParser
}

// One transcript per running process inside its CWD (aider).
type FilesUnderCWD struct {
    Filename string        // basename only, e.g. ".aider.chat.history.md"
    Parser   RawLineParser // FilesUnderCWD always pairs with raw
}

// Session state lives in a structured store, typically SQLite
// (OpenCode → SQLite WAL).
type ProcessOwnedStore struct {
    PathForPID func(pid int) string // resolves the store path for a PID
    Reader     MetricsReader        // bypasses the JSONL-tailer path
}

// File-format dispatch carried inside FilesUnderRoot — JSONL or raw text.
type FileParser interface{ isFileParser() }

type JSONLineParser struct { NewParser func() LineParser }
type RawLineParser  struct { NewParser func() RawParser }

Which canonical scenarios apply to an adapter is no longer a static per-adapter declaration. It is judged per (scenario, adapter) cell by the assess verb of the /ir:onboarding-factory skill across three pillars (agent capability / daemon sensor capture / driver capability), recorded in each cell's replaydata/agents/<name>/scenarios/<cell>/metadata.json. None of it is read by Go daemon code.

Transcript parser — `tailer.TranscriptParser`

Defined in core/pkg/tailer/parser.go. The base contract is one method; raw-text formats (e.g. aider's markdown history) implement the optional RawLineParser in addition.

// Required for every adapter.
type TranscriptParser interface {
    // ParseLine maps one decoded JSONL line into a normalized event.
    // Return nil to silently skip the line.
    ParseLine(raw map[string]interface{}) *ParsedEvent
}

// Optional. Implemented by parsers whose source is not JSONL (aider).
// When present, the tailer skips its JSON pre-parse and hands the
// trimmed line to ParseLineRaw. ParseLine should be a nil-returning no-op.
type RawLineParser interface {
    ParseLineRaw(line string) *ParsedEvent
}

Three further optional hooks are detected by type assertion inside the tailer; implement only the ones the adapter needs.

// Synthesize turn_done when the source format has no in-band end-of-turn marker
// (aider's TUI prompt is not written to the file). The tailer calls IdleFlush
// after each pass with the wall-clock idle time since the last line.
type IdleFlusher interface {
    IdleFlush(idleFor time.Duration) *ParsedEvent
}

// Expose the in-progress turn's cost contribution so the live cost display
// reflects a streaming turn before it commits (Claude Code).
type PendingContributor interface {
    PendingContribution() *PerTurnContribution
}

// Checkpoint and restore stateful per-turn accumulation across daemon
// restarts (Claude Code requestId cursor, Codex cumulative-usage cursor).
type ParserStateProvider interface {
    GetParserLedger() ParserLedger
    SetParserLedger(ParserLedger)
}

The parser's output type, tailer.ParsedEvent, is the normalized contract every transcript format collapses into — event type, tool deltas, token snapshot / per-turn contribution, model, CWD, task deltas, subagent completions, and the user-interrupt / tool-denial flags consumed by the state classifier. See core/pkg/tailer/parser.go for the full struct.

PID discovery — `agent.PIDDiscoverFunc`

Defined in core/domain/agent/discovery.go. Each adapter maps a live session back to the OS process that owns it; strategies vary (CWD-based for Claude Code, transcript-writer for Codex/Pi). The disambiguate callback picks one PID when multiple candidates match.

type PIDDiscoverFunc func(
    cwd, transcriptPath string,
    disambiguate func([]int) int,
) (int, error)

Watcher output — `agent.Event`

Defined in core/domain/agent/event.go. Events carry no adapter field; identity flows through the merge pipeline via Watcher.Identity() (core/ports/inbound/watcher.go).

type EventType string

const (
    EventNewSession EventType = "new_session"
    EventActivity   EventType = "activity"
    EventRemoved    EventType = "removed"
)

type Event struct {
    Type            EventType
    SessionID       string // UUID portion of the filename (no .jsonl)
    ProjectDir      string // leaf directory under the watched root
    TranscriptPath  string // absolute path; for DB-backed adapters: "<db>?session=<id>"
    Size            int64
    CWD             string // working directory of the agent process
    ParentSessionID string // empty unless this is a subagent
}

// The port the daemon consumes. Each per-watcher drain goroutine in
// SessionDetector.Run() captures Identity() once and wraps every event
// with it, so per-adapter identity is a property of the watcher rather
// than the event payload.
type Watcher interface {
    Identity() agent.Identity
    Watch(ctx context.Context) error
    Subscribe() <-chan agent.Event
    Unsubscribe(ch <-chan agent.Event)
}

Outbound Adapters (System Integration)

Outbound adapters handle persistence, process monitoring, real-time communication, and other side effects that flow out of the core.

Filesystem Repository

Package: core/adapters/outbound/filesystem/
Persists session state as JSON files
Atomic writes via temp file + rename
Location: ~/Library/Application Support/Irrlicht/instances/

Process Watcher

Package: core/adapters/outbound/process/
kqueue EVFILT_PROC NOTE_EXIT monitoring
~1ms exit detection latency
Periodic liveness sweep as fallback

WebSocket Hub

Package: core/adapters/outbound/websocket/
Fan-out to all connected clients
Non-blocking sends (drops slow subscribers)
Message types: session_created / session_updated / session_deleted, orchestrator_state

Git Resolver

Package: core/adapters/outbound/git/
Branch detection (strips worktree- prefix)
Project name from git-common-dir (worktree-aware)
CWD extraction from transcript tail (last 32KB)

Metrics Collector

Package: core/adapters/outbound/metrics/
Wraps TranscriptTailer
Extracts model, tokens, tool state, cost

mDNS Advertiser

Package: core/adapters/outbound/mdns/
Bonjour/Zeroconf service advertisement
Service type: _irrlicht._tcp
Includes hostname and IPv4 in TXT records

Logger

Package: core/adapters/outbound/logging/
Structured JSON logging
Auto-rotation at 10MB, 5 files retained

Maturity Stages

Adapters and platforms in the compatibility grid share the same four-tier ladder: planned, alpha, beta, stable. Each tier states a common ladder (time, bug count, real-world use) once and then a small set of component-specific artefact checks. Every box can be ticked from public artefacts (the repo, GitHub issues, tagged releases) -- stage assignment reduces to running through the checklist.

The shape borrows from Kubernetes feature stages (alpha experimental, beta opt-out-able, GA stable) and the CNCF graduation criteria (real adopters, time at the previous tier).

`planned`

Listed in the compatibility grid (README for adapters, homepage for platforms)

`alpha` — scaffolded, smoke path green

Common ladder:

Code lives in the canonical location for its component type
A documented smoke or replay path runs green from a clean checkout

For adapters, additionally:

Adapter package at core/adapters/inbound/agents/<name>/
Exports an agent.Agent from Agent() with the right Source variant (FilesUnderRoot / FilesUnderCWD / ProcessOwnedStore), parser, and PID-discovery hook
Registered in the allAgents slice in core/cmd/irrlichd/main.go
Emits all three lifecycle states: working, waiting, ready
replaydata/agents/<name>/capabilities.json populated against replaydata/agents/features.json
baseline-hello and full-lifecycle-toolcall fixtures committed and replay green via tools/replay-fixtures.sh

For platforms, additionally:

Builds and launches without manual intervention from the standard build script
Smoke path works (renders sessions / receives daemon updates)

`beta` — feature-complete + 30 days real use

Common ladder:

All alpha boxes ticked
At least 30 days since first shipped in a tagged Irrlicht release
At least one public report of real-world use by someone other than the author (GitHub issue, discussion, or PR comment)
Zero open bug-labeled issues against this component on ingo-eichhorst/Irrlicht

For adapters, additionally:

All scenarios in .claude/skills/ir:onboard-agent/scenarios.json whose requires is covered by the adapter's capabilities replay green
Model + cost extraction wired through core/adapters/outbound/metrics/
Subagent / parent-child linkage emits ParentSessionID where the agent supports subagents

For platforms, additionally:

All currently shipped Irrlicht features render correctly on this platform

`stable` — 6 months in use, code is settled

Common ladder:

All beta boxes ticked
At least 180 days since first shipped in a tagged Irrlicht release
Zero bug-labeled issues opened against this component in the last 30 days
Component code is settled: git log <component-path> --since=30.days.ago shows no refactors or new features — only reactive changes (upstream format updates, new platform versions)

For adapters, additionally:

Fixtures regenerated against the agent CLI version currently shipping upstream (matches the relevant entry in min_versions in scenarios.json)

Writing a New Adapter

The end-to-end path for adding an agent adapter -- from process discovery through fixture recording to stage promotion -- is documented under Adding a new agent adapter on the Contributing page. That section drives the /ir:onboard-agent skill, which produces the canonical scenario fixtures used by the criteria above.

Adapters

Inbound Adapters (Event Sources)

Claude Code Adapter

Codex Adapter

Pi Adapter

Aider Adapter

OpenCode Adapter

Process Scanner

Shared File System Watcher

Gas Town Orchestrator

Adapter Interfaces

Adapter declaration — agent.Agent

Transcript parser — tailer.TranscriptParser

PID discovery — agent.PIDDiscoverFunc

Watcher output — agent.Event

Outbound Adapters (System Integration)

Filesystem Repository

Process Watcher

WebSocket Hub

Git Resolver

Metrics Collector

mDNS Advertiser

Logger

Maturity Stages

planned

alpha — scaffolded, smoke path green

beta — feature-complete + 30 days real use

stable — 6 months in use, code is settled

Writing a New Adapter

Adapter declaration — `agent.Agent`

Transcript parser — `tailer.TranscriptParser`

PID discovery — `agent.PIDDiscoverFunc`

Watcher output — `agent.Event`

`planned`

`alpha` — scaffolded, smoke path green

`beta` — feature-complete + 30 days real use

`stable` — 6 months in use, code is settled
