System Design

Hexagonal architecture with clean ports and adapters.

Overview

Irrlicht follows hexagonal (ports-and-adapters) architecture. Every external dependency is behind an interface. Every component is testable in isolation.

Project Structure

core/
├── cmd/
│   ├── irrlichd/          # Daemon entry point
│   └── irrlicht-ls/       # CLI listing tool
├── domain/                # Pure domain types
│   ├── session/           # SessionState, SessionMetrics
│   ├── agent/             # Agent event types
│   ├── orchestrator/      # Orchestrator state
│   └── config/            # Configuration
├── ports/
│   ├── inbound/           # Watcher, OrchestratorWatcher
│   └── outbound/          # Repository, Logger, ProcessWatcher, etc.
├── adapters/
│   ├── inbound/           # Event sources
│   └── outbound/          # System integrations
├── application/services/  # Orchestration logic
└── pkg/                   # Shared utilities (tailer, capacity)

Port Interfaces

Inbound Ports

type Watcher interface {
    Identity() agent.Identity
    Watch(ctx context.Context) error
    Subscribe() <-chan agent.Event
    Unsubscribe(ch <-chan agent.Event)
}

Each watcher carries the identity of the adapter that produced it (Identity().Name — e.g. "claude-code"). The SessionDetector's merge pipeline captures Identity() once per watcher and wraps every event with it, so adapter identity is a property of the watcher, not the event payload.

Outbound Ports

Key interfaces that define outbound boundaries:

• SessionRepository — Persist and retrieve session state
• ProcessWatcher — Monitor process lifecycle (kqueue)
• MetricsCollector — Compute session metrics from transcripts
• GitResolver — Resolve project names from git repositories
• PushBroadcaster — Fan-out state changes to connected clients
• Logger — Structured logging abstraction

Component Wiring

The main.go entry point wires all components together following dependency injection:

1. Logger — structured JSON output
2. Config — loaded from environment variables
3. SessionRepository — filesystem adapter for state persistence
4. GitResolver — resolves project names via git commands
5. MetricsCollector — transcript tailer for session metrics
6. ProcessWatcher — process exit detection behind a portable ports.ProcessObserver seam (build-tagged process_{darwin,linux,other}.go): kqueue on macOS, pidfd on Linux. Adds the Linux daemon without touching any adapter.
7. Watchers — cmd/irrlichd/wiring.go dispatches on each agent.Agent's Source variant: FilesUnderRoot adapters (Claude Code, Codex, Pi) get a shared fswatcher plus a process scanner; FilesUnderCWD (Aider) and ProcessOwnedStore (OpenCode) adapters get a process scanner only. Every watcher exposes Identity() so per-event adapter naming flows through the merge pipeline rather than being stamped at emit time.
8. SessionDetector — thin coordinator that delegates to:
   • StateClassifier — pure functions for working/waiting/ready transitions
   • MetadataEnricher — git metadata, CWD, model, and metrics resolution
   • PIDManager — PID discovery with retry/backoff, process exit handling, liveness sweeps, subagent cleanup
9. PushService — WebSocket fan-out to connected clients
10. HTTP Server — API endpoints + embedded web UI

Data Flow

1. Inbound adapter emits agent.Event
2. SessionDetector receives event, creates or updates session
3. MetricsCollector computes metrics from transcript
4. State machine determines working / waiting / ready
5. PushService broadcasts change via WebSocket
6. SessionRepository persists to filesystem

Performance

Safety Guarantees

• Zero configuration — works out of the box with no setup required
• Idempotent operations — safe to restart at any time
• Non-destructive — never corrupts existing configs or data
• Atomic writes — temp file + rename pattern prevents partial writes
